VW MKV GTI/Rabbit (06-09) Service Manual

A comprehensive must-have for any do-it-yourselfer! Includes 1,792 pages of maintenance, service, and repair information
Mfg Part #
VR09
ECS Part #
ES#260150
Brand
Bentley
95.46
Free Shipping Free Shipping
Availability: Usually Ships in 3 Business Days
Qty
Does this fit my vehicle?

Product Details

The Volkswagen Rabbit, GTI Service Manual: 2006-2009 is a comprehensive source of service information and specifications for Rabbit and GTI models built on the A5 platform from 2006 to 2009. Whether you're a professional or a do-it-yourself Volkswagen owner, this manual will help you understand, care for and repair your vehicle.

Though the do-it-yourself Volkswagen owner will find this manual indispensable as a source of detailed maintenance and repair information, the Volkswagen owner who has no intention of working on his or her car will find that reading and owning this manual will make it possible to discuss repairs more intelligently with a professional technician.

Engines covered
  • 2.0L FSI turbo gasoline (engine code: BPY, CBFA, CCTA)
  • 2.5L gasoline (engine code: BGP, BGQ, CBTA, CBUA)
Transmissions covered
  • 02Q 6-speed manual
  • 09G 6-speed automatic
  • 02E 6-speed DSG
  • 0A4 5-speed manual
Covers Rabbit and GTI models 2006-2009 based on the A5 platform. Maintenance procedures: from oil changes to belt replacement. Engine and cylinder head service, including timing belt replacement for 4-cylinder engines. Removal and installation of Motronic fuel injection system components. Emission control tests, repairs and adjustments, including: Exhaust Gas Recirculation and Secondary Air Injection system. Drivetrain maintenance, troubleshooting, adjustment and repair, including clutch, gearshift linkage, and drive axles. Suspension component replacement, including ball joints, front struts, rear shocks and coil springs. Heating and air conditioning repair, including A/C component replacement on the Climatronic and Climatic systems. Body adjustment and repairs, including front and rear doors, fenders, front radiator support and sunroof. Wiring schematics with fuse/relay locations and easy-to-use illustrated component locator section. Includes R32 wiring diagrams. Volkswagen OBD II diagnostic trouble codes, SAE-defined OBD II P-codes, as well as basic scan tool operation. Comprehensive Volkswagen factory tolerances, wear limits, adjustments, and tightening torques.

This Part Fits the Following Vehicles

Make Model Submodel Engine
Volkswagen Golf V All 2.0T
Volkswagen Golf V All 2.5
Volkswagen Golf V All TDI
