Performance Side Mount Radiator
- Mfg Part #
- 400001006
- ECS Part #
- ES#4000004
- Brand
-
Free Shipping
Product Details
Wagner Tuning Competition Side Water Cooler for AMG A 45, CLA 45 & GLA 45 (M 133) – 77% more volume incl. certificate
Experience maximum performance and thermal stability for your Mercedes AMG A 45, CLA 45, and GLA 45! The Wagner Tuning Competition side water cooler is the essential upgrade for optimizing the cooling performance of your 2.0LM 133 turbo engine. The impressive 77% increase in volume lowers the coolant temperature, improves reliability, and ensures maximum performance – now including parts certificate.
Why this side water cooler is a must-have for your AMG M 133:
Massive volume expansion: The Competition racing intercooler core expands the cooler volume of the side cooler by an impressive +77% (3.15 liters vs. OEM 1.79 liters).
Approved & legal: Now with parts certificate for maximum safety and uncomplicated registration.
Direct performance boost: Effectively lowers the coolant temperature in the indirect intercooler circuit. This improves intercooler cooling and stabilizes system thermodynamics.
Maximum heat transfer: The optimal ratio between internal and external cooling surface ensures maximum heat transfer and sufficient airflow for adjacent components.
Durability & protection: Equipped with a heat-conducting anti-corrosion coating for long-term, reliable cooling and longer system life.
Plug & play installation: Installation is straightforward and virtually plug & play thanks to user-friendly installation instructions.
Technical detail: Cooling circuit optimization for the M 133 turbo engine
The 2.0LM 133 turbo engine in models such as the AMG A 45 (W176) uses an indirect intercooler circuit that employs a separate cooling water circuit to cool the charge air. Lowering the cooling water temperature is the key to increasing performance. The Wagner Tuning side water cooler solves this bottleneck: The 77% increase in volume (3.15 liters vs. OEM 1.79 liters) massively increases the amount of coolant and cooling capacity. The result is more stable system thermodynamics over a longer period of time, which sustainably improves the performance and reliability of your vehicle, especially at high speeds and on the racetrack.
Technical data in direct comparison (OEM vs. Wagner Tuning side cooler)
The Wagner Tuning side water cooler offers decisive advantages over the standard cooler:
Volume: With 3.15 liters, the Wagner Tuning cooler offers 77% more volume compared to the OEM cooler with 1.79 liters.
Dimensions (depth): At 68 mm deep, the coolers are significantly thicker than the standard coolers at 40 mm, which enables increased cooling performance.
Cooling surface:The cooling surface (A) increases by approx. 4% to 464 cm² (vs. OEM 446 cm²).
Cooler core: A high-performance competition racing intercooler core is used.
Dimensions of OEM side radiator:
248 mm x 180 mm x 40 mm
V = 1.79 liters
A = 446 cm²
Dimensions of Wagner Tuning side radiator:
252 mm x 184 mm x 68 mm
V = 3.15 liters
A = 464 cm²
Vehicle compatibility (AMG M 133)
The Wagner Tuning Competition side water cooler is plug-and-play compatible with the following models with the M 133 engine (265-280 kW / 360-381 hp):
Mercedes Benz A 45 AMG W176 (2013-2018)
Mercedes Benz CLA 45 AMG C117 (2013-2018)
Mercedes Benz GLA 45 AMG X156 (2014-2019)
This Part Fits the Following Vehicles
| Make | Model | Submodel | Engine | Year | Chasis | Special Fitment Notes |
|---|---|---|---|---|---|---|
| Mercedes Benz | CLA45 AMG | 4Matic | L4 2.0L | 2015 | 117.352 | Use vehicle selector to confirm fitment |
| Mercedes Benz | CLA45 AMG | 4Matic | L4 2.0L | 2016 | 117.352 | Use vehicle selector to confirm fitment |
| Mercedes Benz | CLA45 AMG | 4Matic | L4 2.0L | 2017 | 117.352 | Use vehicle selector to confirm fitment |
| Mercedes Benz | CLA45 AMG | 4Matic | L4 2.0L | 2018 | 117.352 | Use vehicle selector to confirm fitment |
| Mercedes Benz | CLA45 AMG | 4Matic | L4 2.0L 133.980 | 2019 | 117.352 | Use vehicle selector to confirm fitment |
| Mercedes Benz | CLA45 AMG | Base | I4 2.0L 133.980 | 2014 | 117.352 | Use vehicle selector to confirm fitment |
| Mercedes Benz | GLA45 AMG | 4Matic | L4 2.0L | 2015 | 156.952 | Use vehicle selector to confirm fitment |
| Mercedes Benz | GLA45 AMG | 4Matic | L4 2.0L | 2016 | 156.946 | Use vehicle selector to confirm fitment |
| Mercedes Benz | GLA45 AMG | 4Matic | L4 2.0L | 2017 | 156.952 | Use vehicle selector to confirm fitment |
| Mercedes Benz | GLA45 AMG | 4Matic | L4 2.0L | 2018 | 156.952 | Use vehicle selector to confirm fitment |
| Mercedes Benz | GLA45 AMG | 4Matic | L4 2.0L 133.980 | 2019 | 156.952 | Use vehicle selector to confirm fitment |
